Addressable 2 Loop ABS Fire Control Panel with 440 Devices AC 220V English Color Display for Alarm Systems
Description
Key attributes
| Alarm Type | addressable fire alarm | App Support | addressable fire alarm |
| Feature | addressable fire alarm | Network | addressable fire alarm |
| Model Number | NW-6500 | Place of Origin | Jiangxi,China |
| Detection Range | 100-200 m | Material | ABS |
| Sensor Type | addressable fire alarm | Brand Name | Omnifir |
| Supply Voltage | AC 220 V(110~ 242V)@50/60 Hz | Backup battery | 7AH/12V,2 pcs |
| Bus loop output voltage | DC21V modulating | Capacity of main power supply | 28.5V/14A |
| Linkage power output | 28.5V/3A | Number of manual control disk | 1 |
| Number of manual direct control… | 7 sets | Display mode | English color display |
| Dimension | L400*W500*H115 mm | Net Weight | 11 Kg (with batteries) |
Packaging and delivery
| Selling Units | Single item | Single package size | 61.5X51X23.5 cm |
| Single gross weight | 7.950 kg | ||
Product descriptions from the supplier
Date sheet for 2 loop addressable fire control panel
| Equipment capacity | 1 loops,each with 220 address points |
| Storage capacity | 3000 fire alarm records,3000 linkage records,and 3000 other history records |
| Installation | Standard cabinet construction |
